Mains Ref & Frz
Product Code : LSK-CCE-11300
Mains Ref & Frz (SKU LSK-CCE-11300) is a mains-powered combined vaccine refrigerator and water-pack freezer with 30 litres of net vaccine storage, a freezing capacity of 4 kg of water-packs per 24 hours and room for 16 kg of frozen packs. It suits grid-connected health facilities, vaccine stores and cold-chain training labs. Science Lab Supplies, working from Ambala as a laboratory equipment exporter from India, can include it in quotations for health programmes, contractors and distributors.
Specifications
The table gives every rating of this 30 L mains refrigerator-freezer on a separate row. In summary, it runs on 220–240V 50Hz, uses R600a refrigerant, offers Grade A freeze protection in the vaccine compartment, freezes 4 kg of packs a day and works at ambient temperatures from +5°C to +43°C.
| Specification | Value |
|---|---|
| SKU | LSK-CCE-11300 |
| Type | Mains combined refrigerator and freezer |
| Ambient operating temperature | Min. +5°C, max. +43°C |
| Power requirement | 220–240V, 50Hz |
| Refrigerant | R600a |
| Freeze protection | Grade A |
| Water-pack freezing capacity | 4 kg per 24 hours |
| Water-pack storage capacity | 16 kg |
| Vaccine storage volume category | ≥30 L and <60 L |
| Net vaccine storage volume | 30 L |
| Manuals | User, installation and maintenance documents in English, covering the five aspects of the applicable specification |
| Supplied by | Science Lab Supplies, Ambala, India |
Applications and Experiments for the Mains Refrigerator-Freezer
On a mains supply, this one cabinet stores up to 30 L of vaccines and freezes the water-packs that outreach teams pack into carriers and cold boxes. That pairing suits a health centre running both fixed and outreach sessions, and it gives nursing, ANM and pharmacy trainees a working unit for cold-chain practicals.
- Freezing 0.6 L packs such as the Water pack 0.6L, at up to 4 kg of packs per 24 hours.
- Recording cabinet temperatures with a 30 Day logger, which keeps an OK/ALARM overview for the previous 30 days.
- Spot-checking temperatures with a non-mercury Glass Thermometer graduated in 1°C steps.
- Teaching stock arrangement, temperature charting and freeze-protection checks in immunisation courses.
Standard Scope of Supply
Each unit is delivered as the combined refrigerator and freezer described above, with user, installation and maintenance documents in English covering the five aspects of the applicable specification. Water-packs, thermometers and loggers are separate catalogue items and can be added to the same quotation if needed.
Packing, MOQ and Lead Time
A quotation can cover one refrigerator-freezer for a single clinic or a batch for several facilities. Each one from Science Lab Supplies lists the packing, delivery time and price for the quantity requested, and packs, carriers or loggers can be quoted alongside the unit.
Holding an Importer-Exporter Code, Science Lab Supplies can ship to buyers in South Africa, Qatar, Sri Lanka, Vietnam, Malaysia and Peru. Science Lab Supplies is registered for GST (GSTIN 06ADEPJ0574F2ZU). Send your quantity through the contact page, list the unit in the enquiry cart, or see the lab tender page when a formal bid is involved.
Frequently Asked Questions
What power supply does the Mains Ref & Frz need?
It runs on a 220–240V, 50Hz mains supply. For sites where the grid is unreliable, the solar direct drive units in the same range can be compared on the quotation instead.
How much vaccine and water-pack capacity does it offer?
The vaccine compartment has a net volume of 30 L, which places it in the 30–60 L storage category. Alongside that, it freezes 4 kg of water-packs every 24 hours and stores 16 kg of them.
What does Grade A freeze protection mean here?
Grade A is the freeze-protection rating given for this unit, and the test basis behind it can be confirmed on the quotation. A temperature logger or freeze indicator kept in the cabinet records the conditions the vaccines actually see.
Who supplies the Mains Ref & Frz?
The unit reaches buyers through Science Lab Supplies in Ambala, India, which supplies it rather than building it. One quotation from the team can bundle the refrigerator-freezer with packs, carriers and monitoring devices for the same site.
Related Mains and Solar Cold-Chain Equipment
Larger mains refrigerators, solar units that freeze packs, and the boxes, carriers and freeze indicators used downstream make up the rest of a vaccine cold chain. Any of these can be placed on the same quotation as this 30 L refrigerator-freezer for one facility or a whole district.
- Mains Ref 128L — 128 L mains vaccine refrigerator using R134a refrigerant.
- Mains Refrigerator 184L — 184 L net vaccine volume on 220–240V or 100–127V supplies.
- Solar Direct Drive Ref & Frz. — solar combined unit with a lockable lid and 2 keys.
- Solar Direct Drive Frz. — solar freezer storing 20 kg of water-packs.
- Cold Box — large long-range box holding 20.25 L of vaccines.
- Vaccine Carrier Extra Large — 3 L carrier weighing 7.3 kg fully loaded.
- Freeze Alert — shows a cross if held below -0.5°C for more than 60 minutes.
Browse the full Cold Chain Equipment range, the Clinical Laboratory range for thermometers, or all School Lab Equipments.
