Portable Antenna Aluminium, 12m
Product Code : LSK-CE-11320
Portable Antenna Aluminium, 12m (SKU LSK-CE-11320) is a portable antenna mast kit: a four-section collapsible mast that extends to 12 m and is held by rope guys on a 6 m radius, with a ground plate, erection kit, masthead gibbet and halyard pulley for hoisting an antenna. It suits temporary radio sites and telecom training. Science Lab Supplies, operating from Ambala in India, prepares quotations for the mast kit for institutes, field projects and distributors.
Specifications
The 12 m mast kit’s parts and ratings are given row by row below. In short, it pairs a four-section collapsible mast with rope guys, a ground plate and a masthead gibbet with halyard pulley, carries a 12 kg overhead load in winds up to 144 km/h, and weighs 28.4 kg.
| Specification | Value |
|---|---|
| SKU | LSK-CE-11320 |
| Type | Portable antenna mast kit |
| Mast | Four-section, collapsible |
| Height | 12 m pulled out |
| Guying | Rope guys |
| Guy radius | 6 m |
| Base | Ground plate |
| Erection | Erection kit included |
| Masthead | Masthead gibbet and halyard pulley |
| Overhead load | 12 kg |
| Wind loading | 144 km/h (90 mph) |
| Weight | 28.4 kg |
| Supplied by | Science Lab Supplies, Ambala, India |
Applications and Experiments for the 12 m Portable Antenna Mast
Despite its name, it is a mast kit that lifts an antenna rather than an antenna element itself. Erected on its ground plate and guyed on a 6 m radius, it raises an antenna of up to 12 kg to 12 m, which helps radio range at temporary sites, in winds up to 144 km/h.
- Temporary HF or VHF radio sites for field projects, events and emergency communication set-ups.
- ITI Electronics Mechanic and telecom technician training: guying, raising and lowering a sectional mast safely as a team.
- Checking an antenna feed after erection with the SWR meter in the Tool Kit, f. ICT Technicians, 220 VAC Eqpt.
- Linking classroom theory on antennas and reception, built on the Crystal Radio Receiver Construction Set, to a full-size outdoor installation.
Choose a site well clear of overhead power lines, anchor every guy before raising the sections, and never exceed the 12 kg masthead load. Lower the mast before winds approach its 144 km/h rating.
Standard Scope of Supply
The kit comprises the four-section collapsible mast, rope guys, the erection kit, a ground plate, the masthead gibbet and a halyard pulley. The antenna and its coaxial cable are separate items and can be added to the same quotation together with a radio kit from the range.
Packing, MOQ and Lead Time
One mast kit or several for a network of sites can be quoted. Given the 28.4 kg kit weight, the quotation from Science Lab Supplies describes the packing, delivery time and price for that quantity, and radios or cable can appear on the same document.
With an Importer-Exporter Code, Science Lab Supplies can ship to buyers in Zambia, Rwanda, South Africa, Qatar, Sri Lanka and Vietnam. Science Lab Supplies is registered for GST (GSTIN 06ADEPJ0574F2ZU). Ask about the mast through the contact page, keep it in the enquiry cart with other items, or consult the lab tender page for bids.
Frequently Asked Questions
Is an antenna included with this mast?
The kit is a mast with rope guys, erection kit, ground plate, masthead gibbet and halyard pulley. An antenna and coaxial cable are not part of the mast kit and can be quoted with it separately.
How much load and wind can the mast take?
It is rated for a 12 kg overhead load and wind loading of 144 km/h (90 mph) when properly guyed on its 6 m guy radius with the ground plate in place.
How much ground space does it need?
The rope guys spread on a 6 m radius around the base, so allow a clear circle of about 12 m across, away from power lines, for the fully extended 12 m mast.
Who supplies the Portable Antenna Aluminium, 12m?
The mast kit is quoted and dispatched by Science Lab Supplies, a supplier with its office in Ambala, India. Your enquiry receives one quotation covering the masts, any radios or cable you add, and the freight details.
