Binocular Microscope
Product Code : LSK-M-11368
Binocular Microscope (SKU LSK-M-11368) is an LED-lit compound microscope with a compensation-free binocular head, four achromatic objectives from 4X to 100X and fine focusing graduated in 0.004 mm steps. Optional phase contrast, dark field and polarization attachments extend it beyond bright-field work. It suits college biology, microbiology and life-science laboratories. Science Lab Supplies handles quotations for it from Ambala, India for institutions, distributors and tender buyers.
Specifications
For this LED binocular microscope, the table gives each specification. In short, a 30° head with 48–75 mm interpupillary adjustment sits above a backward quadruple nosepiece, a double-layer 132 x 142 mm stage and an Abbe NA 1.20 condenser with iris, lit by adjustable S-LED illumination.
| Specification | Value |
|---|---|
| SKU | LSK-M-11368 |
| Viewing head | Compensation-free binocular head, inclined at 30° |
| Interpupillary distance | 48–75 mm |
| Eyepiece | WF10x/18 |
| Objectives | Achromatic 4X, 10X, 40X, 100X |
| Magnification range | 40x to 1000x with the WF10x eyepiece |
| Nosepiece | Backward quadruple |
| Stage | Double-layer mechanical stage, 132 x 142 mm |
| Stage travel | 75 x 40 mm |
| Focusing | Coaxial coarse and fine adjustment |
| Focus moving range | 24 mm |
| Fine focus division | 0.004 mm |
| Condenser | Abbe NA 1.20 with iris diaphragm and filter |
| Illumination | S-LED, brightness adjustable |
| Optional accessories | Phase contrast kit, dark field attachment, polarization attachment |
| Supplied by | Science Lab Supplies, Ambala, India |
Applications and Experiments for the Binocular Microscope
In its standard bright-field form the microscope covers stained sections, smears and cell preparations up to 1000x. Adding the optional phase contrast kit allows unstained living cells to be studied, while the dark field and polarization attachments open up further techniques. It fits undergraduate and postgraduate teaching laboratories.
- Microbiology and haematology teaching: stained smears prepared in a Coplin Staining Jar and dried on a Slide Drying Rack.
- B.Sc. biology: tissue sections and cell structure with fine focusing in 0.004 mm divisions.
- With the optional kit, use as a phase contrast microscope in India for unstained cells and protozoa.
- Polarized-light observation of crystals and fibres with the polarization attachment.
Standard Scope of Supply
The standard outfit includes the 30° compensation-free binocular head, WF10x/18 eyepieces, achromatic 4X, 10X, 40X and 100X objectives on the backward nosepiece, the double-layer stage, the Abbe NA 1.20 condenser with iris and filter, and S-LED illumination. Phase contrast, dark field and polarization attachments can be added to the quotation.
Packing, MOQ and Lead Time
Prices can be requested for one microscope or for a laboratory set, with or without the optional attachments. Science Lab Supplies lists packing, delivery time and price for the requested quantity on every quotation, and staining equipment or slides can sit on the same quote.
Holding an Importer-Exporter Code, Science Lab Supplies can ship to buyers in Sri Lanka, Vietnam, Malaysia, Peru, Egypt and Iraq. Science Lab Supplies is registered for GST (GSTIN 06ADEPJ0574F2ZU). For a price, write through the contact page or add the item to the enquiry cart; formal purchasing rounds are covered by the lab tender page.
Frequently Asked Questions
Can this Binocular Microscope be upgraded for phase contrast?
Yes. A phase contrast kit is available as an optional accessory, as are a dark field attachment and a polarization attachment. Ask for the ones you need to be priced on the quotation alongside the microscope.
What kind of illumination does it use?
It uses S-LED illumination with adjustable brightness, which is passed through an Abbe NA 1.20 condenser fitted with an iris diaphragm and filter to control contrast and light intensity.
How fine is the focusing?
Coaxial coarse and fine controls move the stage over a 24 mm range, and the fine adjustment is divided in 0.004 mm steps, which helps when focusing the 100X objective on thin specimens.
Who supplies the Binocular Microscope?
Science Lab Supplies in Ambala, India deals with enquiries for this model. Its team prepares a written quotation that sets out the configuration and any optional attachments, along with packing and dispatch terms for buyers in India and overseas.
