Exhaust Gas Calorimeter
Product Code : LSK-E-10492
Exhaust Gas Calorimeter (SKU LSK-E-10492) is an engine test ancillary that measures the heat carried away in exhaust gases, so students can find the energy lost to exhaust when drawing up an engine energy balance. It suits single-cylinder, four-stroke petrol and diesel engines on the Small Engine Test Set. Science Lab Supplies quotes the calorimeter from Ambala, India, and arranges delivery for engineering colleges, polytechnics, tender contractors and distributors.
Specifications
Each component and sensor of the exhaust calorimeter has its own row in the table. Briefly, exhaust flows through the tubes of a gas-to-water shell and multi-tube heat exchanger inside a jacket of flowing cooling water, and thermocouples, a turbine flow meter and a four-channel display give the data for the heat calculation.
| Specification | Value |
|---|---|
| SKU | LSK-E-10492 |
| Main components | Instrumentation unit, heat exchanger, control valve |
| Heat exchanger | Gas-to-water shell and multi-tube type, on a sturdy base plate |
| Gas and water paths | Exhaust through the tubes; constantly flowing cooling water in the surrounding jacket |
| Measuring method | Cooling-water flow rate with inlet and outlet temperatures |
| Temperature sensors | Thermocouples at gas and water inlet and outlet |
| Flow sensor | Turbine flow meter (cooling water) |
| Display | Digital four-channel temperature and flow display unit |
| Display mounting | Instrumentation rail of the test set console frame |
| Water control | Hand-operated valve on the test set control console |
| Safety | Pressure-relief valve on the heat exchanger for low cooling-water flow |
| Compatible engines | Single-cylinder, four-stroke petrol and diesel engines (separately available) |
| Compatible test sets | Small Engine Test Set; regenerative engine test set |
| Supplied by | Science Lab Supplies, Ambala, India |
Applications and Experiments for the Exhaust Gas Calorimeter
The heat given up by the exhaust equals the heat gained by the cooling water, which students calculate from the water flow rate and its temperature rise. Adding this figure to brake power, cooling losses and fuel energy completes the heat balance sheet of the engine.
- B.Tech/B.E. mechanical: heat balance test on a four-stroke petrol or diesel engine.
- Thermal engineering labs: steady-flow energy calculations on a shell-and-tube exchanger, building on basic calorimetry with the Copper Calorimeter Set.
- Diploma courses: measuring exhaust losses in engine tests.
- Instrumentation practice: comparing the turbine flow meter with the nozzle and other meters on the Flow Meter Calibration apparatus.
Standard Scope of Supply
The calorimeter comprises the instrumentation unit with its digital four-channel display, the shell and multi-tube heat exchanger on its base plate with thermocouples, turbine flow meter and pressure-relief valve, and the hand-operated cooling-water control valve. Engines and the test set are separately available.
Packing, MOQ and Lead Time
We can price the calorimeter on its own or as part of a complete engine test bench, and every quotation states the packing, delivery time and price for what you request. Engines, the test set and the fuel gauge can be added to it.
As a registered exporter with an Importer-Exporter Code, Science Lab Supplies can ship to buyers in Egypt, Iraq, Nigeria, Kenya, Ghana and Ethiopia. Science Lab Supplies is registered for GST (GSTIN 06ADEPJ0574F2ZU). Tell us which test set the calorimeter will join through the contact page, or list it with engines in the enquiry cart; engineering lab equipment in India bought by tender is covered on the lab tender page.
Frequently Asked Questions
How does the calorimeter measure exhaust heat?
Exhaust passes through tubes surrounded by flowing cooling water. From the water flow rate and the inlet and outlet temperatures, students calculate the heat transferred, which gives the energy lost to exhaust.
Which engines can it be used with?
It is intended for single-cylinder, four-stroke petrol and diesel test engines running on the Small Engine Test Set or a regenerative engine test set. The engines are separately available.
What happens if cooling water flow is too low?
The heat exchanger includes a pressure-relief valve for safety in case insufficient cooling water is flowing. Set the water flow with the hand-operated valve before running the engine.
Who supplies the Exhaust Gas Calorimeter?
This energy-balance ancillary is handled by Science Lab Supplies from Ambala in India, which can quote it by itself or within a bench that also includes engines and a test set.
