Transformer Parts Kit
Product Code : SCL-PL-11831
Transformer Parts Kit (SKU SCL-PL-11831) is a set of interchangeable coils, a U and I core, supports and accessories from which students assemble working transformers and related induction demonstrations. It serves Class 12 physics, B.Sc. electricity and magnetism practicals and electrical trade courses. Every kit is manufactured by Science Lab Supplies at Plot 448, HSIIDC Industrial Area, Saha, Ambala, India, and the factory deals with schools, colleges, tender contractors and distributors on each order.
Specifications
Coil turns, core size and every accessory of the transformer kit are entered one per row below. In short, a 32 x 25 mm U and I core takes eight coils from 100 to 1800 turns, so windings can be swapped to change the ratio, while two multimeters, a power source transformer and 50 cm leads handle measurement.
| Specification | Value |
|---|---|
| SKU | SCL-PL-11831 |
| Core | U and I core |
| Core dimensions | 32 x 25 mm |
| Coil, with wings | 100 turns |
| Coil, with wings | 300 turns |
| Coil | 300 turns |
| Coils | 2 x 600 turns |
| Coil | 900 turns |
| Coil | 1200 turns |
| Coil | 1800 turns |
| Support bases | 6 |
| Multimeters | 2 |
| Connecting cables | 8, 50 cm each |
| Power source transformer | Detachable |
| Electric power source | 1 |
| Sector plates | 1 flat, 1 slotted |
| Motor disc | Aluminium |
| Aluminium rings | 1 solid, 1 separate (split) |
| Copper coil | 1 |
| Transformer base | 1 |
| Vertical support rod | 1 |
| Fixings | Tightening screw, screw shafts, tightening plate |
| Nails | 10 |
| Tightening screws | 4 |
| Demonstration table | Transformer demonstration table |
| Manufacturer | Science Lab Supplies, Saha, Ambala, Haryana |
| Country of origin | India |
Applications and Experiments for the Transformer Parts Kit
The kit is used to build step-up and step-down transformers, measure how output voltage follows the turns ratio, and show induced currents with the aluminium rings and sector plates. It fits the electromagnetic induction and alternating current chapters of NCERT Class 12 physics and first-year college practicals.
- Class 12 physics: transformer principle and the link between turns ratio and voltage ratio.
- B.Sc. practical: comparing primary and secondary voltages for different coil pairs; an alternating field can also be probed with a 3300-turn Search Coil.
- ITI Electrician trade: transformer construction and winding ratios, with the Poster - Electromagnetic Induction as a wall reference.
Standard Scope of Supply
Each kit comprises six support bases, the eight coils listed above, the U and I core, two multimeters, eight 50 cm cables, the power source transformer and power source, the sector plates, motor disc, both aluminium rings, a copper coil, a transformer base, a vertical rod, fixing screws and plate, 10 nails, 4 tightening screws and a transformer demonstration table.
Packing, MOQ and Lead Time
Quotations can cover one kit or enough kits for every bench in a laboratory, and each one lists the packing, delivery time and price for the quantity requested. Other physics lab equipment in India from the same range can be added to that quotation.
Holding an Importer-Exporter Code, Science Lab Supplies can ship to buyers in Vietnam, Malaysia, Peru, Egypt, Iraq and Nigeria. Quote requests for one kit or a full bench run can be lodged on the contact page or through the enquiry cart, and the lab tender page outlines institutional tendering.
Frequently Asked Questions
Which coils come with the Transformer Parts Kit?
Eight coils: 100 and 300 turns with wings, plus 300, two of 600, 900, 1200 and 1800 turns. Pairing them on the core gives many step-up and step-down ratios.
Are meters included?
Yes. Two multimeters are part of the set, so primary and secondary readings can be taken together, and eight 50 cm cables are supplied for wiring.
Is Science Lab Supplies the manufacturer or a trader?
Coils, core and fittings of this kit are produced and packed at the Science Lab Supplies works in Saha, Ambala, India, so the manufacturer issues each quotation with no trading intermediary involved.
Related Transformer and Induction Equipment
These Physics Lab and Electrical and Electronics items deal with the same transformer and induction topics as the parts kit, so a build-your-own transformer bench can sit beside ready-made transformers, induction coils and Lenz's law demonstrations. Any of them can be quoted together with the kit on one sheet.
- Transformer — fixed windings: a 400-turn secondary with 200-turn and 800-turn primaries.
- Multitap Transformer — 0, 2, 3, 8 and 12 V AC taps at 6 A continuous, in a metal case.
- Induction Coils with Cores — cored induction coils carrying up to 5 A.
- Apparatus for Studying the Production of Electricity by Induction — 75 mm coils of 700 and 1150 turns.
- Faraday's and Lenz's law Demonstration Set — 38 mm copper ring and neodymium magnet in a PVC guide tube.
- Lenz's Law — open and closed loops reacting to a moving magnet.
- Electric Motors — twelve iron magnets, six shafts and a 2–14 V AC/DC supply.
