Advanced School Microscope
Product Code : LSK-M-11357
Advanced School Microscope (SKU LSK-M-11357) is a monocular compound microscope with a quadruple revolving nosepiece, achromatic 10x, 40x and 100x oil immersion objectives, an Abbe NA 1.25 condenser and a graduated 120 x 120 mm mechanical stage. It suits senior school and college biology where cells, tissues and stained smears are studied. Science Lab Supplies provides this microscope from Ambala, India to schools, colleges, tender contractors and distributors.
Specifications
The Advanced School Microscope is specified line by line below. In short, it has a die-cast aluminium stand, a monocular tube inclinable to 90°, separate coarse and fine focusing with a down-movement stopper, mirror illumination through a rack-mounted Abbe condenser, and a choice of Huygenian or wide-field eyepieces.
| Specification | Value |
|---|---|
| SKU | LSK-M-11357 |
| Body | Monocular tube inclinable up to 90° |
| Mechanical tube length | 160 mm |
| Stage | Graduated mechanical stage, 120 x 120 mm |
| Slide movement | Up to 40 x 75 mm |
| Coarse focusing | Rack and pinion |
| Fine focusing | Screw-lever mechanism with graduated knob on the right side |
| Safety device | Adjustable down-movement stopper to protect slides |
| Stand | Aluminium die-cast parts |
| Nosepiece | Quadruple revolving, positive centering and click stops |
| Condenser | Bright field Abbe, NA 1.25, iris diaphragm, swing-out filter holder, rack and pinion movement |
| Illumination | Plano-concave mirror, 50 mm diameter, on gimbal mount |
| Eyepieces | Huygenian 5x, 6x, 10x, 15x (any two) or wide field 10x |
| Objectives | Achromatic 10x, 40x SL and 100x SL oil immersion |
| Accessories | Vinyl cover, duster, cleaning brush, filter |
| Packing | Full mould Styrofoam/Thermocol container |
| Optional extras | Coaxial mechanical stage, wooden cabinet with lock and key, draw tube, spare objectives, sub-stage lamp for 220/110 V |
| Supplied by | Science Lab Supplies, Ambala, India |
Applications and Experiments for the Advanced School Microscope
With three achromatic objectives up to 100x oil immersion, this microscope takes students from tissue sections to stained bacteria. The graduated mechanical stage moves a slide in measured steps, the iris diaphragm controls contrast, and the down-movement stopper protects slides when high-power objectives are in use.
- Class 11–12 biology: plant and animal cells, tissues and cell division slides.
- B.Sc. microbiology and botany: viewing the Bacteria slide Set of 12, some of which need 1000x magnification.
- Measurement practicals: calibrating the eyepiece with the 1 mm Micrometric Slide, divided in 0.01 mm steps.
- Organising a slide collection in the Microscope Slide Box for 100 Slides between practicals.
Standard Scope of Supply
The microscope comes with its monocular body, quadruple nosepiece, 10x, 40x SL and 100x SL oil immersion objectives, two eyepieces of your choice, the Abbe condenser, 50 mm mirror, vinyl cover, duster, cleaning brush and filter, packed in a full-mould Styrofoam container. Optional extras are quoted at extra charge.
Packing, MOQ and Lead Time
Quotations can cover a single unit or a full class set, and each one gives packing, delivery time and price for that quantity. The eyepiece pair and any optional extras are set out on the quote, and prepared slides can be added for a complete student microscope bench.
Under its Importer-Exporter Code, Science Lab Supplies is able to ship to buyers in Uganda, the UAE, Saudi Arabia, Oman, the Philippines and Nepal. Share your requirement on the contact page, line up several items in the enquiry cart, or check the lab tender page for institutional tenders.
Frequently Asked Questions
Which eyepieces can be chosen?
Any two Huygenian eyepieces from 5x, 6x, 10x and 15x, or a wide field 10x eyepiece. Name your choice when asking for the quotation so the microscope is supplied with the pair your syllabus needs.
Is the 100x objective an oil immersion lens?
Yes. The objectives are achromatic 10x, 40x SL and 100x SL oil immersion. The 100x lens is used with a drop of immersion oil for the highest magnification, for example when looking at stained bacteria.
What optional extras are available?
A coaxial mechanical stage, a wooden storing cabinet with lock and key, a draw tube, spare objectives and a sub-stage lamp for 220/110 V can be added at extra charge and are listed separately on the quotation.
Who supplies the Advanced School Microscope?
It is supplied by Science Lab Supplies from Ambala, India. Biology departments, tender contractors and distributors can include it with prepared slides, slide boxes and other microscopes in a single quotation.
